URD MAF Sensor Calibrator – UNIVERSAL

$249.99 $210.00

Product Options

Description

*If you plan on installing a turbo in the future, please buy the MAF calibrator with MAP sensor option*

Have you been looking for a cost effective way to tap into some of that hidden power?  Have you been looking for a way to get that expensive cat-back exhaust system to live up to your expectations?  Has your expensive aftermarket air intake system let you down?  You need the ability to retune your ECU for these aftermarket upgrades to get the performance gains you expect.

The URD MAF Sensor Calibration Unit allows fuel curve retuning to find that hidden power you are looking for.  The URD MAF Sensor Calibrator and your tuning will tie all of your performance modifications together, unleashing all the power available from them.

The URD MAF Sensor Calibrator is basically the fuel control half of our very successful URD MAF/Timing Calibrator that URD included in our Supercharger Performance Upgrade Kits for years.  We know that not everyone needs timing control, and removing the timing control function saves you a lot of money.

The URD MAF Sensor Calibrator intercepts the signal from the Mass Airflow Sensor and remaps it optimizing the fuel mixture for the best power and performance.  It is the ability to retune that optimizes your modifications allowing them to work together as they should.

It is programmed using included tuning software based on manifold pressure or throttle position (depending on version) and RPM.  The software has more resolution than any other end user fuel computer in this price range.  You will need a Window PC and a serial port or USB to serial adapter to connect to the unit for tuning.

We offer two basic URD MAF Sensor Calibrator versions. One is primarily for normally aspirated vehicles that use the signal from the throttle position sensor as the load scale indicator and one with a Manifold Absolute Pressure Sensor (MAP Sensor).  The unit with the MAP sensor senses the manifold pressure and is primarily for engines that have forced induction.

The unit for normally aspirated engines can be used for:

  • Optimizing the fuel mixture for best power on stock or modified engines
  • Correcting MAF Sensor error caused by aftermarket intake systems
  • Remapping the fuel curve to compensate for high flow headers, exhaust systems, and cams

The unit with the MAP sensor for engines with forced induction systems can be used for:

  • Optimizing the fuel mixture for best power
  • Retuning the ECU for larger then stock fuel injectors
  • Retuning for increased boost levels

Here is a typical example of how effective the URD MAF Sensor Calibrator can be.  This is a dyno chart from a totally stock 2005 Tacoma X-Runner.  As you can see there was a hidden 15 Rear Wheel Horse Power (RWHP) just waiting to be unleashed.  Results from totally stock vehicles typically yield 8-15+ RWHP.  We even found 15 RWHP on a totally stock Camry.

If you have been considering some other end user tunable fuel computer for your vehicle we think you will find that most of them have the resolution of a very dull butter knife and cost you much more then our solution.

Our map table is truly three dimensional and has 61 load columns and 16 RPM rows for a total of 986 map table cells all of which are directly accessible.  Each cell has 200 levels of adjustment.  There is nothing else out there that is this easy to tune with this level of map resolution in this price range, NOTHING.  Only the best from URD.

The units can be used on any 0-5 volt sensor, but are primarily used to recalibrate the MAF Sensor signals.  If you wish to modify some other 0-5 volt circuit based on RPM and TPS/Manifold Pressure the unit can be applied to your needs.

The unit ships with the tuning software and a vehicle specific connection guide for the vehicles listed below.  Just select the vehicle you have and the appropriate guide will be included for you.  If you have some other vehicle not listed, the unit will ship with a generic connection guide to assist you in your installation.

These are great units. We have even used these calibrators on Lamborghini and Ferrari MAF Sensor based vehicles with fantastic results.

Please contact info@urdusa.com with any questions.

When placing your order please tell us what vehicle, engine, and year you will be installing the URD MAF Sensor Calibrator into and what perfromance modifications are already installed on the vehicle.  This will allow us to include the correct installation guide and in some cases we have a calibration file that may perfectly fit your combination and will pre-load that before we ship the unit to you.  We have many calibrations for the 1GR-FE and 2TR-FE engines with many of the more popular intakes.  If we do not have calibration file specific to your combination a “BLANK” map will be loaded so you can install the unit and the vehicle will drive normally until you start your custom tuning.

Please put the info requested in the COMMENTS box in the check out.

Year Make Model Engine
Year Make Model Engine
2010 - 2015 Toyota Tundra V8 4.6L 1UR-FE
2010 - 2015 Toyota Sequoia V8 4.6L 1UR-FE
2010 - 2015 Toyota 4Runner I4 2.7L 2TR-FE
2009 Toyota Venza V6 3.5 2GR-FE
2009 Toyota Venza I4 2.7 2TR-FE
2009 Toyota RAV4 I4 2.5 1AR-FE
2009 Toyota Matrix I4 2.4 2AZ-FE
2009 Toyota Matrix I4 1.8 2ZR-FE
2008 - 2015 Toyota Sequoia V8 5.7L 3UR-FE
2008 - 2015 Toyota Landcruiser V8 5.7L 3UR-FE
2008 - 2014 Lexus Lexus LX V8 5.7 3UR-FE
2008 - 2009 Toyota Sequoia V8 4.7L 2UZ-FE
2008 - 2009 Toyota Landcruiser 4.0L V6
2008 - 2009 Toyota Corolla I4 2.4 2AZ-FE
2008 - 2009 Toyota Corolla I4 1.8 2ZR-FE
2008 - 2009 Scion Scion xB I4 2.4 2AZ-FE
2008 - 2009 Lexus Lexus ISF V8 5.0 2UR-GSE
2007 - 2015 Toyota Tundra V8 5.7L 3UR-FE
2007 - 2014 Toyota FJ Cruiser V6 4.0L 1GR-FE
2007 - 2009 Toyota Camry V6 3.5 2GR-FE
2007 - 2009 Toyota Camry I4 2.4 2AZ-FXE (Hybrid)
2007 - 2009 Scion Scion xD I4 1.8 2ZR-FE
2006 - 2009 Toyota RAV4 V6 3.5 2GR-FE
2006 - 2009 Lexus Lexus GS V8 4.6 1UR-FE
2006 - 2009 Lexus Lexus GS V6 3.5 2GR-FSE
2005 - 2015 Toyota Tundra V6 4.0L 1GR-FE
2005 - 2015 Toyota Tacoma V6 4.0L 1GR-FE
2005 - 2015 Toyota Tacoma I4 2.7L 2TR-FE
2005 - 2009 Toyota Yaris I4 1.5 1NZ-FE
2005 - 2009 Toyota Avalon V6 3.5 2GR-FE
2005 - 2009 Scion Scion tC I4 2.4 2AZ-FE
2005 - 2009 Lexus Lexus IS 350 V6 3.5 2GR-FSE
2005 - 2009 Lexus Lexus IS 250 V6 2.5 4GR-FSE
2005 - 2006 Toyota Corolla I4 1.8 2ZZ-GE
2004 - 2008 Toyota Solara V6 3.3 3MZ-FE
2004 - 2008 Toyota Solara I4 2.4 2AZ-FE
2004 - 2008 Toyota RAV4 I4 2.4 2AZ-FE
2004 - 2007 Scion Scion xB I4 1.5 1NZ-FE
2004 - 2006 Toyota Camry V6 3.3 3MZ-FE
2004 - 2006 Scion Scion xA I4 1.5 1NZ-FE
2003 - 2015 Toyota 4Runner V6 4.0L 1GR-FE
2003 - 2009 Toyota 4Runner V8 4.7L 2UZ-FE
2003 - 2009 Lexus Lexus GX V8 4.7 2UZ-FE
2003 - 2008 Toyota Matrix I4 1.8 1ZZ-FE
2003 - 2006 Toyota Matrix I4 1.8 2ZZ-GE
2002 - 2009 Toyota Camry I4 2.4 2AZ-FE
2001 - 2009 Toyota Prius I4 1.5 1NZ-FXE
2001 - 2007 Toyota Sequoia 4.7L V8
2000 - 2009 Toyota Tundra V8 4.7L 2UZ-FE
2000 - 2005 Toyota Celica I4 1.8 2ZZ-GE
2000 - 2005 Toyota Celica I4 1.8 1ZZ-FE
2000 - 2004 Toyota Tundra V6 3.4L 5VZ-FE
1999 - 2003 Toyota Solara V6 3.0 1MZ-FE
1999 - 2003 Toyota Solara I4 2.2 5S-FE
1998 - 2007 Toyota Landcruiser 4.7 V8
1998 - 2007 Toyota Corolla I4 1.8 1ZZ-FE
1998 - 2007 Lexus Lexus LX V8 4.7 2UZ-FE
1998 - 2005 Lexus Lexus GS V8 4.3 3UZ-FE
1998 - 2004 Lexus Lexus IS 300 I6 3.0 2JZ-GE
1997 - 2006 Toyota Camry V6 3.0 1MZ-FE
1997 - 2001 Toyota Camry I4 2.2 5S-FE
1996 - 2002 Toyota 4Runner V6 3.4L 5VZ-FE
1996 - 2002 Toyota 4Runner I4 2.7L 3RZ-FE
1996 - 1997 Lexus Lexus LX I6 4.5 1FZ-FE
1995 - 2004 Toyota Tacoma V6 3.4L 5VZ-FE
1995 - 2004 Toyota Tacoma I4 2.7L 3RZ-FE
1995 - 2004 Toyota Tacoma I4 2.4L 2RZ-FE
1995 - 2004 Toyota Avalon V6 3.0 1MZ-FE
1995 - 1998 Toyota T-100 V6 3.4L 5VZ-FE
1995 - 1998 Toyota T-100 I4 2.7 L 3RZ-FE
1995 - 1997 Toyota Corolla I4 1.8 7A-FE
1994 Toyota T-100 I4 2.7 3RZ-FE
1994 - 2003 Toyota RAV4 I4 2.0 3S-FE
1994 - 1999 Toyota Celica I4 1.8 7A-FE
1993 Toyota T-100 V6 3.0 3VZ-E
1993 - 2002 Toyota Supra I6 3.0 2JZ-GTE
1993 - 2002 Toyota Supra I6 3.0 2JZ-GE
1991 - 2005 Lexus Lexus GS I6 3.0 2JZ-GE
1991 - 1997 Lexus Lexus GS V8 4.0 1UZ-FE
1991 - 1992 Toyota MR2 3S-GTE
1990 - 1999 Toyota Celica I4 2.2 5S-FE
1990 - 1993 Toyota Celica I4 2.0 3S-GTE
1990 - 1993 Toyota Celica I4 1.6 4A-FE
1989 - 1992 Toyota Supra I6 3.0 7M-GTE
1989 - 1992 Toyota Supra I6 3.0 7M-GE
1988 - 1995 Toyota 4Runner V6 3.0 3VZ-E
1985 - 1995 Toyota 4Runner I4 2.4 22R-E
1984 - 1986 Toyota 4Runner I4 2.4 22R

Additional information

Weight 2.00 lbs
Dimensions 7.00 × 4.00 × 7.00 in
